Which one is stronger, 304 stainless steel security camera poles or Q235B carbon steel rod?

In the fields of security engineering, road traffic monitoring, etc., the material selection of security camera poles directly affects the stability and service life of the equipment. 304 stainless steel and Q235B carbon steel are two mainstream materials, and their strength differences often become the focus of selection disputes.



I. Comparison of basic material properties

1. Chemical composition and microstructure

Q235B carbon steel has a carbon content of 0.12%- 0.20%. Manganese and silicon are the main alloying elements; it is a low-carbon steel. Its metallographic structure is mainly ferrite + pearlite, with coarse grains and easy-to-form dislocation slip.

304 stainless steel: contains 18%-20% chromium, 8%-10.5% nickel, and carbon content ≤0.08%. The austenite structure gives it high ductility, and the chromium element forms a passivation film that significantly improves corrosion resistance.

2. Material standards

Q235B implements GB/T 700 standard, with a yield strength of ≥235MPa;

304 stainless steel implements GB/T 20878, with a yield strength of ≥205MPa (solid solution state).

2. Measured data of mechanical properties

1. Static strength index

Yield strength: Q235B (235MPa) > 304 stainless steel (205MPa)

Tensile strength: Q235B (375-500MPa) < 304 stainless steel (515-690MPa)

Note: 304 can increase its yield strength to more than 800MPa through cold working (such as cold drawing).



II. Dynamic mechanical performance

Impact toughness: 304 stainless steel still maintains good toughness at -196℃, while Q235B is easily brittle at low temperatures.

Fatigue strength: The fatigue limit of 304 (about 240MPa) is significantly higher than that of Q235B (about 180MPa), which is suitable for a long-term wind vibration environment.



III. Differences in environmental adaptability

1. Corrosion resistance

The annual corrosion rate of Q235B in a humid environment can reach 0.1-0.2mm, and hot-dip galvanizing (zinc layer ≥85μm) is required to achieve a 10-year lifespan;

The annual corrosion rate of 304 stainless steel in a C4-level corrosion environment (such as industrial areas and coastal areas) is <0.001mm, and the maintenance-free life is over 25 years.

2. Extreme climate tolerance

Typhoon area: The density of 304 is 8.0g/cm³, which is higher than that of Q235B at 7.85g/cm³. With high tensile strength, the wind load resistance is increased by 15%-20%;

Salt spray environment: The corrosion rate of Q235B is accelerated after the galvanized layer is damaged, and the 304 passivation film has self-repairing properties.

IV. Influence of processing and structural design

1. Differences in manufacturing processes

Q235B can be welded with CO₂ gas shielding, which has high welding efficiency but the heat-affected zone is easy to soften;

304 requires TIG welding, which increases the processing cost by 30%, but the weld strength can reach more than 90% of the parent material.

2. Lightweight design potential

Using the high tensile strength ratio of 304 (tensile strength/yield strength of 2.5), the rod's wall thickness can be reduced by 10% to 15%, achieving a 20% weight reduction without reducing the load-bearing capacity.



V. Economic analysis of the entire life cycle

| Indicators | Q235B + hot-dip galvanizing | 304 stainless steel |

|---------------|----------------------|--------------------|

| Initial cost | ￥6000/ton | ￥15000/ton |

| Maintenance cycle | 5-year re-galvanizing (￥2000/time) | No maintenance required |

| 20-year total cost | ￥6000+3×2000=￥12000| ￥15000 |

| Residual value rate | 30% | 70% (100% recyclable) |



The data shows that in a use cycle of more than 10 years, the comprehensive cost of 304 stainless steel is lower.



VI. Recommendations for typical application selection

1. Scenarios where Q235B is preferred

Short-term temporary monitoring projects (<5 years)

Dry inland climate + budget-constrained projects

Structures that require frequent modification and adjustment

2. Scenarios where 304 stainless steel must be used

Highly corrosive environments such as coastal areas and chemical plants

Typhoon-resistant design (such as wind speed >40m/s)

The permanent infrastructure of smart cities



Conclusion

In terms of pure mechanical strength, the yield strength of Q235B carbon steel is better than that of 304 stainless steel in its basic state, but its tensile strength and fatigue performance are at a disadvantage. In actual engineering, 304 stainless steel can increase its yield strength to more than 3 times that of Q235B through cold working hardening, and with excellent weather resistance, it has become the first choice for high-end security camera poles. It is recommended to use a 20-year service life as the evaluation benchmark and give priority to 304 stainless steel if the initial cost allows, to maximize the comprehensive benefits of the entire life cycle.
